隨著行業逐步邁進自動化應用的時代，節約人力成本必然成為一種趨勢。
我公司推出新型循環式儲坯機，正是這樣一款由儲坯籠和升降輸送輥臺組成的適用于窯爐燒成前 / 后磚坯緩存的新型儲坯設備。
As the industry gradually moves into the era of automation applications, saving labor costs will inevitably become a trend.
Our company introduced a new type of cycling compensator, which is a new type of stocking equipment consisting of a stock cage and an
elevating conveyor roller table suitable for caulking the front and rear bricks in the kiln.
產品優勢
Product Advantage
生產線進窯前所有工段，包括送料車間、壓機車間、釉線車間工作人員只需要工作 12 小時，即可滿足窯爐日產量 14000 平方米。大大節約了人力以及電能。
All the production sections before kiln, including the feed section, press section, glaze line section' s staff only need to work 12 hours, to meet the
daily output of 14,000 square meters furnace. Great savings in manpower and electricity
循環式儲坯機配置大容量的緩存儲坯籠，以 800 x 800 ( mm ) 的磚坯為例，設置 30 個儲坯籠。每個儲坯籠最大可達到 259.2m² 的緩存量，并實現智能控制。
在正常 12 小時工作時間內，由釉線輸送過來的磚坯，分成兩部分控制 : - 部分正常進窯燒成，多出部分由循環式儲坯機智能送進緩存儲坯籠內，儲滿后
使用 AGV 無人搬運車自動運送到儲坯籠停放區存放。當整條生產線正式儲坯機智能送進緩存儲坯籠內，儲滿后使用 LGV 無人搬運車自動運送到儲坯籠
停放區存放。當整條生產線正常工作 12 小時，窯前所有工段停止工作，循環式儲坯機自動使用 LGV 無人搬運車把儲坯籠停放區內的儲坯籠按照先后順
序運送到升降輸送輥臺處，把儲存的磚坯按先進先出原則把磚坯輸送進窯爐。
The cycling compensator is equipped with a large- -capacity, buffer- storage blank cage. For example, an 800 x 800 (mm) green tile is used to set
30 stock cages. Each storage cage can achieve a maximum buffer of 259.2m2 and achieve intelligent control.
In the normal 12- -hour working time, the tiles conveyer by the glaze line are divided into two parts: a part of the normal incoming kiln is burned,
and the excess part is intelligently fed into the buffer storage cage by the circulating stocker and used after being full. AGV unmanned vans are
automatically transported to the storage area for storage of cages. When the entire production line works normally for 12 hours, all sections in the
kiln stop working, and the circulating stocker automatically uses the LGV unmanned van to transport the storage cages in the storage area of the
cage to the elevating conveyor roller table in the sequence. The stored bricks are conveyed into the furnace on a first- in-first- -out basis.
產品亮點
Product highlights
智能循環儲坯系統使用的 LGV 無人搬運車，在完全不需要人的前提下，能夠沿設定的激光導航引路行駛，具有安全保護以及各種移載功能，透過電腦指
令控制源源不斷地補充儲坯籠容量，滿足生產需求。使用激光導航系統，使運行路線靈活多變 , 隨意設定更改線路，特別是轉產品時特別方便實用。
The LGV unmanned van used in the intelligent circular billet storage system can travel along the set laser The LGV unmanned van used in the
intelligent circular billet storage system can travel along the set laser the computer. The order control source continuously supplements the capacity
of the bank cage to meet production requirements.' The use of a laser navigation system makes the running route flexible and allows you to change
the route at your disposal. This is especially convenient and practical when you switch products.
AGV 無人搬運車能夠人工固定在某個地點充電，也可以在不工作的情況下自動去到某充電站自行充電。電量自動檢測，當檢
測到電量低于設定值，AGV 無人搬運車會自行給電池充電，無需要操作人員介入。電池可多次重復充電。
產品升級
Product Advantage
可配置“互聯網 +”技術 : 通過 Ethernet\wifi\3G\4G 網絡， 嵌入云端技術， 實現數據采集和分析處理，全方位實時監控生產。
The AGV unmanned truck can be manually fixed at a certain place to charge, or it can automatically go to a charging station to charge itself when it is not working. Automatic detection of electricity, when the detected power is lower than the set value, AGV unmanned van will charge the battery by itself, no need for operator intervention. The battery can be repeatedly charged. [product upgrade]: Configurable "Internet +" technology: Through the Ethernet \ wifi \ 3G \ 4G network,embedded cloud technology, data acquisition and analysis and processing, all-round real-time monitoring of production.
