釉線翻坯機是瓷磚因特殊工藝需要反面進入干燥窯烘干，出窯后需翻轉正面進入施釉線而在施釉線工段增設的設備。輥棒采用同步帶及直齒輪傳動，以保證運行的穩定性及設備維護的方便性。
本設備輥棒采用了剛性比其他管材更好的優質冷拔鋼管制作, 外套采用耐磨橡膠；外圓使用本公司自主研發的磨棒設備加工，圓跳動達到了 +0.3mm 之內, 直線度高 , 使輥棒運轉更平穩定，杜絕輥棒跳動造成的磚坯暗裂等缺陷 ; 使設備整體重量更輕，陶瓷產品輸送過程更平穩可靠；傳動上用了優質同步帶 , 使設備運行過程噪音更低 , 震動更小，使用壽命更長，設備維護更便捷。
The machine is added if ceramic needs to be overturned upside down in order to convey into the drying kiln and then turned back to the glazing line. The roller is driven by conveyance belts and spur gears, ensuring conveyance stability and maintenance convenience.
The roller of this equipment is made of quality cold drawn pipe with rigidity better than other pipes and coated with durable rubber. The outer ring is processed by the milling equipment developed by Lile, which ensures the circumferential runout precision 土 0.3mm and boasts high straightness. The design ensures roller running stability, avoids hidden crack and defects caused by roller runout., and reduces overall weight of the equipment and ensures conveyance stability and reliability of ceramic products. The conveyance belt is of high quality,which reduces equipment noise and vibration, prolongs service life, and facilitates equipment maintenance.
